STRAND Cyclorama 300W RGBALC

The Strand Coda LED Cyc is a high output theatrical cyc luminaire that provides rich color mixing for seamless coverage of a stage’s cyclorama. The RGBALC (Red, Green, Blue, Amber, Lime & Cyan) color mixing system on the Strand Coda LED off ers rich colors using a wide mixable color spectrum, but it can be easily controlled with traditional CYM controls using the SmartColor Control system. With two zone color control, it is easy to create natural-looking split-color cyc coverage.

FEATURES AND BENEFITS
- High output LED cyc - modern theatrical cyc with quality you can trust.
- High CRI RGBALC Color System with SmartColor Control - wide range of vivid color options that can be programmed using CYM
- Independent color mixing and temperature controls - match color palette to color temperature without manual adjustment for simpler programming
-Two -zone color control - create natural looking split colors
- Fanless design - perfect for use in quiet environments
- Wide coverage per fi xture - 2.5m (8.5ft) coverage @ 1.2m (4ft) fromprojection surface
- Adjustable frequency to exceed camera frame rates - camera friendly fixtures for IMAG, event recordings, or TV & fi lm applications
SOURCE Type: Luxeon C RGBALC LED , 75pcsx3W
OPTICAL PERFORMANCE
Dimming 16-bit dimming, Dim Snap on / off DMX control, Tungsten amber shift optional on/off DMX control
Dimming curves: Square Law , Linear , S-Curve
CCT: 2,700 - 10,000K
Max lumen output : 13.110
Strobe: Standard, Lightning and Random
CRI: RA 94 (CCT3200) . R9 96
TM30-15: Rf 88 , Rg 105
TLCI: TBC
Duv (Delta UV) : 0.0006
TV flicker free Yes; adjustable 12 Hz to 25 kHz frequency adjustments
BEAM: Beam angle 40° x 60°
COLOR CONTROL
Color mixing: RGBALC , Direct control or CYM,CTO+Green magenta
CTO / CTB: Variable control 2,700 - 8,000K
Camera adjustments: Magenta / Green shift control
Color presets: 33 predefined calibrated colors and 20 user-definable color presets
CONTROLS
Control data protocols: DMX - RDM
Data input: 5-pin DMX In/Thru
DMX modes:Smart Color Control-13*/23 Channels (*default) | Color Mode - 4 Channels | Open Color Control-17/29 Channels "
Pixel / cell control options : 1 / 2
Fan control not required; fanless fixture
POWER
Range 100 - 240VAC
Connector type Input/Thru
Max wattage
240V 214W and 120V 223W
ENVIRONMENT
Cooling system: Convection cooling
Operating temp: 0°-40°C
Construction; Cast aluminium
Standard finish: Raven black
IP rating: IP20
PHYSICALS: Hanging 1/2 turn omega camps for quick hanging or floor mount use
DIMENSIONS: (H x W x D) mm
Fixture only: 508 x 335 x326
Packed: 635 x 410 x 500
WEIGHT kg: Fixture only Net 15 | Packed Gross 18
