TOA MIXER AMPLIFIER 4 INPUTS 120W/100V 5 ZONES

The VM-2120 is a multifunctional amplifier that can be mounted in an EIA-Standard equipment rack (3-unit size). The unit comes with 4 audio inputs including the background music input, and the speaker output section which has an internal attenuator and 5-zone selector. It permits not only general-purpose broadcast, but also Emergency Broadcast based on the EN60849 Standard which gives pre-recorded voice instructions in the emergency situation. Broadcast can be made from an optional RM-200M Remote Microphone as well as from the amplifier, and can be remotely controlled from external equipment. In addition, the unit features the surveillance function which automatically checks the system for failures. An optional EV-200M Voice Announcement Board is required. An optional SV-200M Surveillance Board is required.
Spec:
Power Source AC mains
Rated Output 120 W
Output Voltage/Impedance 100 V/83 ohms, 70 V/42 ohms, 50 V/21 ohms (selectable by the internal wiring change)
Frequency Response 50 - 16,000 Hz
Distortion Under 1%
S/N Ratio Over 60 dB
Tone Control Bass: 100 Hz +/-10 dB, Treble: 10 kHz +/-10 dB
(Inputs 1 - 3 and BGM individually adjustable.)
Input Inputs 1 - 3: -60 dB (MIC)/-10 dB (LINE) (changeable),
600 ohms, electronically balanced,
Telephone paging input: Push-in terminal block
BGM 1 - 2: -20 dB, 10 kohms, RCA pin jack,
Power amplifier input: 0 dB, 10 kohms, RCA pin jack
External speaker line input: 100 V line, for All-Zone Broadcast
Output Speaker output: Plug-in screw connector
5-zone selector with attenuator
Direct speaker line output: Direct output from the power amplifier
output transformer (attenuator bypassed),
Line output: 0 dB, 10 kohms, RCA pin jack
Recording output: 0 dB, 10 kohms, RCA pin jack
ssPreamplifier output: 0 dB, 10 kohms, RCA pin jack
