VOX STRIKE FUZZ PEDAL

TRIKE FUZZ.
Tone Garage captures the pure essence of analog in these compact effect units by pairing carefully selected components with a unique design philosophy.
The TRIKE FUZZ octave pedal offers a unique tonal signature from Tone Garage’s all analog circuitry.

Main features:
- Discrete circuitry - the result of a relentless design philosophy.
- True bypass design provides tonal confidence even when the effect is off.
- Tough die-cast body that stands up to the rigors of the road.
- A versatile octave fuzz that gives you up to three octaves at once.
- Three different octave modes.
- Uses a special diode with a response similar to a germanium diode

An octave fuzz with three types of octave settings.
This is an octave fuzz overflowing with vintage character, utilizing specially selected diodes. It covers not only a range of one octave up, but also two octaves down. You can choose three types of octave settings: +1 or, -1 and -2, or all upward and downward octaves to obtain thick vintage fuzz sounds. In addition, there's a tone control for +1 octave and a volume control for -2 octave. Since the Trike Fuzz operates the downward octave circuits in series and combines them in parallel with the upward octave at the end, you can create a diverse range of sounds that cannot be obtained with existing octave fuzz units.

VOX TRIKE FUZZ Specifications:
- Input impedance: 680kΩ.
- Output impedance: 2.2k Ω.
- Connections: INPUT jack (guitar input), OUTPUT jack (line output).
- Power: AA battery x 6 / AC adapter / DC 9V (Option).
- Consumption current: 14mA.
- Battery Life: Approximately 280 hours.
- Dimensions: (W x D x H): 87 x 132 x 63 / mm, 3.43 x 5.20 x 2.48 / inch.
- Weight: 420 g / 14.81 oz (not including battery).
- Accessories: AA alkaline battery x 6 (for verifying operation).
- Options: AC Adapter.
